Water Spray Chamber

Water ingress test chamber can perform the combined test of IPX1 X2 X3 X4 X5 X6 in one chamber.
Name: water ingress test chamber
Model: RD-800C
Capacity: 800L/1000L/1500L/2000L and more
Standard: IEC 60529, ISO20653
Drip Tray Size: 800*800
IP Rate: IPX1 X2 X3 X4 X5 X6, IPX6K

LIB rain chamber can perform reliability in compliance with the test standards EN60529.
Name: rain test equipment
Model: RD-1200C
Swing Angle of Oscillating Tube: 0 ~ ±180°
Standard: IEC 60529, ISO20653
Drip Tray Size: 800*800
Oscillating Tube Radius 800mm

Rain spray test chamber to test the IPX3 and IPX4 protection degree against rain and sprays according to IEC 60529.
Name: rain spray test chamber
Model: RD-1200C
Swing Angle of Oscillating Tube: 0 ~ ±180°
Standard: IEC 60529, ISO20653
Drip Tray Size: 800*800
Turntable: 1r/min Adjustable;

LIB designed and produced different size and configuration of ipx3 x4 test chamber.
Name: ipx3 x4 test chamber
Model: R-1200C
Swing Angle of Oscillating Tube: 0 ~ ±180°
Standard: IEC 60529, ISO20653
Drip Tray Size: 800*800
Capacity: 800L/1000L/1500L/2000L and more
Door Lock: Electromagnetic lock;

Water spray jetting chamber can perform the combined test of IPX3 X4 X5 X6 in one chamber.
Model: RD-1200C
Capacity: 800L/1000L/1500L/2000L and more
Jet nozzles: IPX5: Dia6.3mm, IPX6: Dia12.5mm
Jet distance: 2.5~3meter
Door Lock: Electromagnetic lock;
Application: Lamps, Electric cabinets;
Standard: IEC 60529, ISO20653;

Our IPX8 Test Equipment enables the sample place in the immersion tank at a distance of at least 1m from the bottom of the sample to the surface of the water.
Name:IPX7 IPX8 immersion tester
Model: R78-600
Pressure: 50m water depth pressure
Open mode: Pneumatic lid
Material : A3 steel plate, wall thickness 15mm
Controller: Programmable touch screen controller
Water Supply System: Storage water tank, Automatic water supply
The tank is of cylindrical design, and the bottom must be supported by a tripod.

MIL STD 810 G Rain Test Chamber can perform reliability in compliance with the test standards MIL STD 810.
Name:MIL STD 810 G Rain Test Chamber
Final rain droplet velocity: 9m/s on test item
Rainfall rate: ≥ 1.7 mm/min
Droplet size: 0.5mm ~ 4.5mm
Test specimen heating range: Water temperature +10°C (max +55°C)
Test time: 0 ~ 999min. adjustable
Nozzle pressure: 276kpa
Rainfall rate: 20.8L/min
Droplet size: 0.5mm ~ 4.5mm

LIB designed and produced different size and configuration of rain test chamber.
Name: Splash Water Test Chamber
Model: RD-1200C
Capacity: 800L/1000L/1500L/2000L and more
Standard: IEC 60529, ISO20653
Drip Tray Size: 800*800
Water System: Water Circulation System;

UL 50E Rain Test Apparatus to test the IPX3 and IPX4 protection degree against rain and sprays according to IEC 60529.
Name: UL 50E Rain Test Apparatus
Model: RD-1200C
Swing Angle of Oscillating Tube: 0 ~ ±180°
Standard: IEC 60529, ISO20653
Drip Tray Size: 800*800
Turntable: 1r/min Adjustable;

JIS D0203 Rain Test Chamber can perform the combined test of IPX3 X4 X5 X6 in one chamber.
Model: R-1000JIS Capacity: 1000L/1500L/2000L and more
Door Lock: Electromagnetic lock;
Application: Lamps, Electric cabinets;
Standard: JIS D0203;

JIS D 0203 R1 R2 Rain Test Equipment can perform the combined test of IPX3 X4 X5 X6 in one chamber.
Model: R-1000JIS Capacity: 1000L/1500L/2000L and more
Door Lock: Electromagnetic lock;
Application: Lamps, Electric cabinets;
Standard: JIS D0203;

Blowing rain test chamber can perform reliability in compliance with the test standards MIL STD 810.
Name:blowing rain test chamber
Final rain droplet velocity: 9m/s on test item
Rainfall rate: ≥ 1.7 mm/min
Droplet size: 0.5mm ~ 4.5mm
Test specimen heating range: Water temperature +10°C (max +55°C)
Test time: 0 ~ 999min. adjustable
Nozzle pressure: 276kpa
Rainfall rate: 20.8L/min
Droplet size: 0.5mm ~ 4.5mm
