environmentally controlled chamber

This environmentally controlled chambers come in two three including benchtops, reach-in chambers and walk-in chambers
Name: humidity test chamber
Model: TH-100
Lowest Temperature: -20℃/-40℃/-60℃/-70℃;
Temperature Range:-20℃～+150 ℃;
Humidity Range:20% ~ 98% RH;
Refrigerant: Environmental refrigerant;

Send Inquiry

Product Description

Environmentally controlled chamber Manufacturer & Supplier

LIB Industry environmentally controlled chamber allows testing of products under controlled temperature and humidity conditions. They consist of an insulated enclosure with a humidity generator and temperature control system.

75+ Different models for choose. This temperature humidity chambers come in two types including reach-in chambers and walk-in chambers. Extended choice of options fitted to your testing. You can select your chamber from the door, refrigeration system, controller, language and so much more. Provide temperature, climate, vibration, corrosion, altitude, pressure combined test.

Technical Specifications

Model	TH-100	TH-225	TH-500	TH-800	TH-1000
Internal Dimension (mm)	400500500	500600750	700800900	80010001000	100010001000
Overall Dimension (mm)	90010501620	100011401870	120013402020	130015402120	150015402140
Interior Volume	100L	225L	500L	800L	1000L
Heat load	1000W
Temperature Range	A : -20℃ ～ +150 ℃ B : -40℃ ～ +150 ℃ C: -70℃ ～ +150 ℃
Temperature Fluctuation	± 0.5 ℃
Temperature Deviation	± 2.0 ℃
Humidity Range	20% ~ 98% RH
Humidity Deviation	± 2.5% RH
Cooling Rate	1 ℃ / min
Heating Rate	3 ℃ / min
Cooling system	Mechanical compression refrigeration system
Refrigerating unit	French TECUMSEH compressor
Heating Element	Nichrome heater
Controller	Programmable color LCD touch screen controller, Ethernet connection
Water supply system	Automatic water supply, Water purification system
Humidifier	External isolation, stainless steel surface evaporation humidifier
Safety Device	Humidifier dry-combustion protection; over-temperature protection; over-current protection; Refrigerant high-pressure protection; Water shortage protection; Earth leakage protection
Exterior Material	Steel Plate with protective coating
Interior Material	SUS304 stainless steel
Thermal Insulation	Polyurethane foam and insulation cotton
Observation Window	Interior lighting, double-layer thermo stability silicone rubber sealing
Standard Configuration	1 Cable hole with plug; 2 shelves
